Dimensions
Dimensions
Transport Length
41.59ft in
Transport Width
7.62ft in
Transport Height
12.46ft in
Ground Clearance
1.43ft in
Width W/ Outriggers Extended
22.97ft in
Carrier Length
36.37ft in
Upper Structure Tail Swing Radius
11.08ft in
Boom
Min Height @ Max Raise Angle
37ft in
Max Height @ Max Raise Angle - No Jib
141ft in
Min Working Radius
8ft in
Max Working Radius
130ft in
Max Elevating Angle
82degrees
Max Lift Capacity
165000lb
Number Of Sections
6
Specifications
Carrier Engine
Make
Grove
Model
OM 470A
Gross Power
429.2hp
Power Measured @
1700rpm
Max Torque
1548.9lb ft
Torque Measured @
1300rpm
Operational
Operating Weight
88218lb
Number Of Axels
4
Upper Structure Fuel Capacity
105.7gal
Upper Structure Hydraulic System Fluid Capacity
118.9gal
Operating Voltage
24V
Alternator Supplied Amperage
150amps
Tire Size
385/95 R25
Transmission
Transmission Type
Mercedes G 280
Number Of Forward Gears
16
Number Of Reverse Gears
2
Max Speed - Forward
48.8mph
